GR40 Suspension (Subaru XV & Crosstrek)

$ 5,200.00

SKU: N/A Categories: ,

The GR50 is our 1-way adjustable (rebound) novice level rally suspension. It features an inverted shock, 50mm piston/ 62mm body, 20 points of rebound adjustment, Eibach 70mm I.D. springs, and a 1-piece assembly (mounting tabs and threaded body are one unit vs the traditional modular assembly with an adjustable/ removable lower mount). The GR50 features 6-8” of travel. The entire body is electroplated to prevent corrosionGR50 is only available for Subaru GC/GD and SF/SG chassis.

The GR-PRO is our 3-way adjustable (rebound/ high & low speed compression) professional level rally/ rallycross suspension. It features an inverted shock with external reservoirs, 40mm piston/ 52mm body, 20 points of rebound adjustment with 10 points of high and low speed compression adjustment, Magnitude springs (main and helper),  and a 1-piece assembly (mounting tabs and threaded body are one unit vs the traditional modular assembly with and adjustable/ removable lower mount). The GR-PRO will feature 6-8” of travel*. The entire body will be electroplated to prevent corrosion.

SPECIFICATIONS:

  • Designed for Heavy Duty Offroad
  • Adjusts from 1-3" over OEM ride height
  • 2 Front Inverted Assemblies
  • 2 Rear Assemblies with External Reservoirs
  • 40mm Inverted Shock Insert
  • Radial bearing on Front Assembly
  • KING Linear Rate Springs
  • Highly Polished Electro-Plated Nickel Cartridge
  • Rebuildable Inverted Shock
  • CNC Machined High-flow Aluminum Piston
  • Stainless Steel Shims
  • Light Weight Synthetic Shock Oil
  • Rebound Adjustable : 20 pts
  • Brackets for Sensor Lines on shock body
  • Individual Parts Available
  • Approx 3wks to hand assemble and ship

Additional information

Weight 20 kg
Dimensions 70 × 45 × 20 cm
Crosstrek (XV) Options

GD (18'-21), GP (13'-17')

Front Shock Top Mount Style

Camber Plate, OEM Hybrid, Offset Spherical Bearing

Rear Spring Rate

Comfort, Overload
